| Item # | Wheel Diameter |
Wheel Base |
120 fpm Motor |
Wheel Load |
Moving Mass |
Suggested List Price* |
Specifications * |
|---|---|---|---|---|---|---|---|
| HS-250.330.2700 | 10 in | 8-10 | 2 x 3.0 hp | 29250 lbs | 64000 lbs | Click for Prices | HS 250-Specifications |
| HS-250.330.2900 | 10 in | 9-6 | 2 x 3.0 hp | 29250 lbs | 64000 lbs | Click for Prices | |
| HS-250.330.3200 | 10 in | 10-6 | 2 x 3.0 hp | 29250 lbs | 64000 lbs | Click for Prices | |
| HS-250.330.3800 | 10 in | 12-6 | 2 x 3.0 hp | 29250 lbs | 64000 lbs | Click for Prices | |
| HS-250.330.4600 | 10 in | 15-0 | 2 x 3.0 hp | 29250 lbs | 64000 lbs | Click for Prices |
| Item # | Wheel Diameter |
Wheel Base |
120 fpm Motor |
Wheel Load |
Moving Mass |
Suggested List Price* |
Specifications * |
|---|---|---|---|---|---|---|---|
| HS-315.405.2700 | 12 in | 8-10 | 2 x 4.0 hp | 38850 lbs | 91520 lbs | Click for Prices | HS 315-Specifications |
| HS-315.405.2900 | 12 in | 9-6 | 2 x 4.0 hp | 38850 lbs | 91520 lbs | Click for Prices | |
| HS-315.405.3200 | 12 in | 10-6 | 2 x 4.0 hp | 38850 lbs | 91520 lbs | Click for Prices | |
| HS-315.405.3800 | 12 in | 12-6 | 2 x 4.0 hp | 38850 lbs | 91520 lbs | Click for Prices | |
| HS-315.405.4600 | 12 in | 15-0 | 2 x 4.0 hp | 38850 lbs | 91520 lbs | Click for Prices |
| Item # | Wheel Diameter |
Wheel Base |
120 fpm Motor |
Wheel Load |
Moving Mass |
Suggested List Price* |
Specifications * |
|---|---|---|---|---|---|---|---|
| HS-400.480.3200 | 16 in | 10-6 | 2 x 7.5 hp | 52000 lbs | 169500 lbs | Click for Prices | HS 400-Specifications |
| HS-400.480.3800 | 16 in | 12-6 | 2 x 7.5 hp | 52000 lbs | 169500 lbs | Click for Prices | |
| HS-400.480.4100 | 16 in | 13-6 | 2 x 7.5 hp | 52000 lbs | 169500 lbs | Click for Prices | |
| HS-400.480.4600 | 16 in | 15-0 | 2 x 7.5 hp | 52000 lbs | 169500 lbs | Click for Prices |
| Item # | Wheel Diameter |
Wheel Base |
120 fpm Motor |
Wheel Load |
Moving Mass |
Suggested List Price* |
Specifications * |
|---|---|---|---|---|---|---|---|
| HS-500.650.3200 | 20 in | 10-6 | 2 x 7.5 hp | 60000 lbs | 180000 lbs | Click for Prices | HS 500-Specifications |
| HS-500.650.3800 | 20 in | 12-6 | 2 x 7.5 hp | 60000 lbs | 180000 lbs | Click for Prices | |
| HS-500.650.4100 | 20 in | 13-6 | 2 x 7.5 hp | 60000 lbs | 180000 lbs | Click for Prices | |
| HS-500.650.4600 | 20 in | 15-0 | 2 x 7.5 hp | 60000 lbs | 180000 lbs | Click for Prices |
| Item # | Wheel Diameter |
Wheel Base |
120 fpm Motor |
Wheel Load |
Moving Mass |
Suggested List Price* |
Specifications * |
|---|---|---|---|---|---|---|---|
| HS-630.825.3900 | 24.75 in | 12-10 | 2 x 7.5 hp | 76000 lbs | 180000 lbs | Click for Prices | HS 630-Specifications |
| HS-630.825.4400 | 24.75 in | 14-5 | 2 x 7.5 hp | 76000 lbs | 180000 lbs | Click for Prices | |
| HS-630.825.4600 | 24.75 in | 15-0 | 2 x 7.5 hp | 76000 lbs | 180000 lbs | Click for Prices |
* Subject to minor variations.
